Chief® White 1' x 2' Above Suspended Ceiling Storage Box

Model #: CMS491

$345.60

At a Glance

The CMS491 conceals AV equipment above a 2' X 2' ceiling tile to provide a clean professional look for classrooms and conference rooms. Drop carriage door improves accessibility and serviceability providing full access to equipment.

WarningProposition 65 Warning for California Residents
Chief® White 1' x 2' Above Suspended Ceiling Storage Box

General

ColorWhite
Overall Dimensions (H x W x D)8" x 12.97" x 23.67" (203 x 329 x 601 mm)
CertificationsUL Listed, TAA Compliant
Adjustments100 lbs ( 45.4 kg)
Max Equip Size H x W x D7.61" x 19.25" x 12" (193 x 489 x 305 mm)
Shipping Weight30 lbs (13.61 kg)

General Specs

ColorWhite
Depth (in.)23.67
Width (in.)12.97
Height (in.)8
Weight Kilogram13.61
Color Finish NameWhite
Width (cm)32.9
Height (cm)20.3
Depth (cm)60.1

Chief® White 1' x 2' Above Suspended Ceiling Storage Box

Model #: CMS491
939016
Model #: CMS491
Chief
$345.60

Price Starting At

$345.60

At a Glance

The CMS491 conceals AV equipment above a 2' X 2' ceiling tile to provide a clean professional look for classrooms and conference rooms. Drop carriage door improves accessibility and serviceability providing full access to equipment.

Get to know this product.

The CMS491 conceals AV equipment above a 2' X 2' ceiling tile to provide a clean professional look for classrooms and conference rooms.

Drop carriage door improves accessibility and serviceability providing full access to equipment

Detachable power housing can be pre-installed with electricians on site and assembled to the storage boxat a later time

Inside the box or facing the room

Up to 2 single gang or 1 dual gang outlet

4 nested knockouts for 1-1/4", 1", & ½" diameter conduit

Built in ventilation

AV tray supports a variety of AV components

Ships with 1 shelf, 2nd shelf sold separately see CMSUNV1

Overall weight capacity 100 lbs (45 kg)

50 lbs (22 kg) for projector ceiling plate

25 lbs (11 kg) per shelf location

Ships with speed connect installation hardware

Lightweight construction, one man installation

UL evaluated for use in Air-Handling Spaces as defined by Article 300.22, Sub-clause (C) of the NEC.

TAA Compliant

Specifications

General Specs

ColorWhite
Depth (in.)23.67
Width (in.)12.97
Height (in.)8
Weight Kilogram13.61
Color Finish NameWhite
Width (cm)32.9
Height (cm)20.3
Depth (cm)60.1

General

ColorWhite
Overall Dimensions (H x W x D)8" x 12.97" x 23.67" (203 x 329 x 601 mm)
CertificationsUL Listed, TAA Compliant
Adjustments100 lbs ( 45.4 kg)
Max Equip Size H x W x D7.61" x 19.25" x 12" (193 x 489 x 305 mm)
Shipping Weight30 lbs (13.61 kg)
